Factory direct; Free samples; Customizable; MoQ:50PCS
Application field:
Track record of data acquisition
Automatic vehicle location
Driving recorder
Navigation
GPS clock and digital camera
Child/elderly/personal locator and security system
Main Technical Specifications:
| Set 10HZ output, dynamic test precision in open zone | |
| Receiver Type | 72-channel 8030 engine |
| GPS & QZSS:L1 C/A,1575.42MHz, | |
| GLONASS | |
| L1OF, | |
| 1598.0625~1605.375MHz | |
| GALILEO/BEIDOU | |
| B1 1561.098 MHz | |
| SBAS: WAAS, EGNOS, MSAS | |
| Horizontal | 2.5m (Autonomous) |
| Position | 2.0m (WAAS) |
| Accuracy | (including SBAS & QZSS; CEP, 50% |
| 24hr static, -130dBm, >6 SVs) | |
| Velocity | 0.05 m/s (speed) |
| Accuracy | <0.3(heading) |
| (50%@30m/s) | |
| Time Pulse | 30ns (RMS) |
| Signal Accuracy | <60ns (99%) |
| Time Pulse Frequency | 0.25 Hz ~ 10 MHz |
| Time To First Fix Hot start Cold start | Autonomous |
| 1.5 sec | |
| 26 sec | |
| (50% -130dBm) | |
| Sensitivity (Autonomous) | -148dBm (acquisition) |
| -167dBm (tracking) | |
Navigation. Update Rate | Max. 10Hz, GPS & GLONASS or |
| GPS & Beidou | |
| Max. 18Hz, GPS only | |
| Default 1Hz | |
| Max. Altitude | 50,000 m |
| Max. Velocity | <1,852 km/hr |
| Protocol Support | NMEA 0183 v2.3 and V4.x |
| UART: 9600 bps N,8,1; | |
| GGA, GLL, GSA, GSV, RMC, VTG, TXT | |
| SBAS Support | WAAS, EGNOS, MSAS |
Packing&Shipping
Carton size: 30cmx30cmx20cm
Packing Qty:100pcs
Gross weight: 2KG/carton
Shipping way: DHL/UPS/TNT/FedEx/EMS etc.
Packing details can be negotiable.
