Factory direct; Sample free( within 5pcs,you have to take shipping costs); MoQ: 50pcs
Applications:
BNC are widely used in connection with the RF coaxial cables in TV,computer field, network of wireless, medical equipment and electronic instrument.
Specifications:
Major Technical Characteristics | MATERIAL & PLATING | |||
Temperature Range: | -55~+155°C(PE Cable -40~+85°C) | |||
Impedance: | 50Ω, 75Ω | Body | brass | Nickel plated |
Frequency Range: | DC~4GHz | |||
Working Voltage: | 500V r.m.s at sea level | Resilient contact | Tin bronze | Gold or silver plated |
Withstanding Voltage: | 1500V r.m.s at sea level | |||
Contact resistance: | a)Center Contact ≤1.5m Ω b)Outer Contact ≤1m Ω | Pin contact | brass | Gold or silver plated |
Insulation resistance: | ≥5000MΩ | Socket contact | Beryllium-copper | Gold or silver plated |
Center Conductor retention force: | ≥0.57N | insulator | PTFE | |
Insertion Loss | ≤0.20dB/3GHz | Crimp ferrule | Copper alloy | Nickel plated |
Voltage Standing Wave Ratio: | Straight ≤1.22/ 3GHz Right angle ≤1.30/3GHz | Hot Tags: Send Inquiry
| ||
